CNC File Add-On (DXF) - Tall and Extra Tall Seat Rail Plans

For plans buyers who are cutting the seat rails on a CNC. You get clean DXF files for both rail heights, Tall (6-1/2") and Extra Tall (8"), ready to import into your CNC software. Choose inches or millimeters above.

• Two toolpath views in every file. Top view: the rail face, with the outline and the 5/16" shaft holes. Side view: the rail's top edge, with the 21/64" bolt holes that run through the full rail height. Each view has both rails, on its own layers.
• Check your machine for the side view. It needs a CNC that can hold the rail on end and drill 6-1/2" or 8" deep. If yours can't, the top view marks where the bolt holes go. Drill them after cutting with a drill press, or the HA Woodworks Seat Rail Drill Guide.
• Requires the Tall and Extra Tall Seat Rail Plans. The file has no instructions. Hardware and steps are in the plans.
• Made for you: each file is prepared by hand for your order and emailed to you within 2 business days.
• Tell us who is cutting it in the box above Add to cart, so we can prepare the file for that shop.
